Specifications / Range :
- Type: SPM, CNC, vertical spindle, single, multiple pass
- Bore Range: 15 – 50 mm
- Max. Stroke : 700 mm
- Spindle Speed : 60 – 900 rpm (infinitely variable)
- Spindle Drive : 5 HP / 1440 rpm
- Spindle Speed Controls : Through VFD
- Reciprocation speed: 18m / min (Max)
- Hone Expansion: Hydraulic, self expanding
- Honing Sticks : Diamond
- CNC Servo Slide for Reciprocation : 250 x 400 Top Slide, 700 mm stroke length
- Rotary Table Size / Weight Carrying Capacity : 800 mm dia / 650 Kg
- Component Material : Cast iron, steel
- No. of Spindles : 1 Spindle 2 spindles (rotary/standalone) (roughing & finishing) 3 spindles rotary (roughing, finishing & super finishing)
